Cloud Data Architecture Overview

The cloud is changing the way applications are designed, including how data is processed and stored. Instead of a single general-purpose database that handles all of a solution’s data, polyglot persistence solutions use multiple, specialized data stores, each optimized to provide specific capabilities. The perspective on data in the solution changes as a result. There are no longer multiple layers of business logic that read and write to a single data layer. Instead, solutions are designed around a data pipeline that describes how data flows through a solution, where it is processed, where it is stored, and how it is consumed by the next component in the pipeline.

Traditional RDBMS workloads. These workloads include online transaction processing (OLTP) and online analytical processing (OLAP). Data in OLTP systems is typically relational data with a predefined schema and a set of constraints to maintain referential integrity. Often, data from multiple sources in the organization may be consolidated into a data warehouse, using an ETL process to move and transform the source data.

Big data solutions. A big data architecture is designed to handle the ingestion, processing, and analysis of data that is too large or complex for traditional database systems. The data may be processed in batch or in real time. Big data solutions typically involve a large amount of non-relational data, such as key-value data, JSON documents, or time series data. Often traditional RDBMS systems are not well-suited to store this type of data. The term NoSQL refers to a family of databases designed to hold non-relational data. (The term isn’t quite accurate, because many non-relational data stores support SQL compatible queries.)

These two categories are not mutually exclusive, and there is overlap between them, but we feel that it’s a useful way to frame the discussion. Within each category, the guide discusses common scenarios, including relevant Azure services and the appropriate architecture for the scenario. In addition, the guide compares technology choices for data solutions in Azure, including open source options. Within each category, we describe the key selection criteria and a capability matrix, to help you choose the right technology for your scenario.

This guide is not intended to teach you data science or database theory — you can find entire books on those subjects. Instead, the goal is to help you select the right data architecture or data pipeline for your scenario

Online transaction processing (OLTP)

The management of transactional data using computer systems is referred to as online transaction processing (OLTP). OLTP systems record business interactions as they occur in the day-to-day operation of the organization, and support querying of this data to make inferences.

Transactional data

Transactional data is information that tracks the interactions related to an organization’s activities. These interactions are typically business transactions, such as payments received from customers, payments made to suppliers, products moving through inventory, orders taken, or services delivered. Transactional events, which represent the transactions themselves, typically contain a time dimension, some numerical values, and references to other data.

Transactions typically need to be atomic and consistent. Atomicity means that an entire transaction always succeeds or fails as one unit of work, and is never left in a half-completed state. If a transaction cannot be completed, the database system must roll back any steps that were already done as part of that transaction. In a traditional RDBMS, this rollback happens automatically if a transaction cannot be completed. Consistency means that transactions always leave the data in a valid state. (These are very informal descriptions of atomicity and consistency. There are more formal definitions of these properties, such as ACID.)

Transactional databases can support strong consistency for transactions using various locking strategies, such as pessimistic locking, to ensure that all data is strongly consistent within the context of the enterprise, for all users and processes.

The most common deployment architecture that uses transactional data is the data store tier in a 3-tier architecture. A 3-tier architecture typically consists of a presentation tier, business logic tier, and data store tier. A related deployment architecture is the N-tier architecture, which may have multiple middle-tiers handling business logic.

Typical traits of transactional data

Transactional data tends to have the following traits:

When to use this solution

Choose OLTP when you need to efficiently process and store business transactions and immediately make them available to client applications in a consistent way. Use this architecture when any tangible delay in processing would have a negative impact on the day-to-day operations of the business.

OLTP systems are designed to efficiently process and store transactions, as well as query transactional data. The goal of efficiently processing and storing individual transactions by an OLTP system is partly accomplished by data normalization — that is, breaking the data up into smaller chunks that are less redundant. This supports efficiency because it enables the OLTP system to process large numbers of transactions independently, and avoids extra processing needed to maintain data integrity in the presence of redundant data.

Challenges

Implementing and using an OLTP system can create a few challenges:

• OLTP systems are not always good for handling aggregates over large amounts of data, although there are exceptions, such as a well-planned SQL Server-based solution. Analytics against the data, that rely on aggregate calculations over millions of individual transactions, are very resource intensive for an OLTP system. They can be slow to execute and can cause a slow-down by blocking other transactions in the database.
• When conducting analytics and reporting on data that is highly normalized, the queries tend to be complex, because most queries need to de-normalize the data by using joins. Also, naming conventions for database objects in OLTP systems tend to be terse and succinct. The increased normalization coupled with terse naming conventions makes OLTP systems difficult for business users to query, without the help of a DBA or data developer.
• Storing the history of transactions indefinitely and storing too much data in any one table can lead to slow query performance, depending on the number of transactions stored. The common solution is to maintain a relevant window of time (such as the current fiscal year) in the OLTP system and offload historical data to other systems, such as a data mart or data warehouse.

Applications such as websites hosted in App Service Web Apps, REST APIs running in App Service, or mobile or desktop applications communicate with the OLTP system, typically via a REST API intermediary.

In practice, most workloads are not purely OLTP. There tends to be an analytical component as well. In addition, there is an increasing demand for real-time reporting, such as running reports against the operational system. This is also referred to as HTAP (Hybrid Transactional and Analytical Processing).

Key selection criteria

To narrow the choices, start by answering these questions:

• Do you want a managed service rather than managing your own servers?
• Does your solution have specific dependencies for Microsoft SQL Server, MySQL or PostgreSQL compatibility? Your application may limit the data stores you can choose based on the drivers it supports for communicating with the data store, or the assumptions it makes about which database is used.
• Are your write throughput requirements particularly high? If yes, choose an option that provides in-memory tables.
• Is your solution multitenant? If so, consider options that support capacity pools, where multiple database instances draw from an elastic pool of resources, instead of fixed resources per database. This can help you better distribute capacity across all database instances, and can make your solution more cost effective.
• Does your data need to be readable with low latency in multiple regions? If yes, choose an option that supports readable secondary replicas.
• Does your database need to be highly available across geo-graphic regions? If yes, choose an option that supports geographic replication. Also consider the options that support automatic failover from the primary replica to a secondary replica.
• Does your database have specific security needs? If yes, examine the options that provide capabilities like row level security, data masking, and transparent data encryption.

Data warehousing (DW)

A data warehouse is a centralized repository of integrated data from one or more disparate sources. Data warehouses store current and historical data and are used for reporting and analysis of the data.

To move data into a data warehouse, data is periodically extracted from various sources that contain important business information. As the data is moved, it can be formatted, cleaned, validated, summarized, and reorganized. Alternatively, the data can be stored in the lowest level of detail, with aggregated views provided in the warehouse for reporting. In either case, the data warehouse becomes a permanent data store for reporting, analysis, and business intelligence (BI).

When to use a DW?

Choose a data warehouse when you need to turn massive amounts of data from operational systems into a format that is easy to understand. Data warehouses don’t need to follow the same terse data structure you may be using in your OLTP databases. You can use column names that make sense to business users and analysts, restructure the schema to simplify relationships, and consolidate several tables into one. These steps help guide users who need to create reports and analyze the data in BI systems, without the help of a database administrator (DBA) or data developer.

Consider using a data warehouse when you need to keep historical data separate from the source transaction systems for performance reasons. Data warehouses make it easy to access historical data from multiple locations, by providing a centralized location using common formats, keys, and data models.

Because data warehouses are optimized for read access, generating reports is faster than using the source transaction system for reporting.

Other benefits include:

• The data warehouse can store historical data from multiple sources, representing a single source of truth.
• You can improve data quality by cleaning up data as it is imported into the data warehouse.
• Reporting tools don’t compete with the transactional systems for query processing cycles. A data warehouse allows the transactional system to focus on handling writes, while the data warehouse satisfies the majority of read requests.
• A data warehouse can consolidate data from different software.
• Data mining tools can find hidden patterns in the data using automatic methodologies.
• Data warehouses make it easier to provide secure access to authorized users, while restricting access to others. Business users don’t need access to the source data, removing a potential attack vector.
• Data warehouses make it easier to create business intelligence solutions, such as OLAP cubes.

Challenges

Properly configuring a data warehouse to fit the needs of your business can bring some of the following challenges:

• Committing the time required to properly model your business concepts. Data warehouses are information driven. You must standardize business-related terms and common formats, such as currency and dates. You also need to restructure the schema in a way that makes sense to business users but still ensures accuracy of data aggregates and relationships.
• Planning and setting up your data orchestration. Consider how to copy data from the source transactional system to the data warehouse, and when to move historical data from operational data stores into the warehouse.
• Maintaining or improving data quality by cleaning the data as it is imported into the warehouse.

Key selection criteria

To narrow the choices, start by answering these questions:

• Do you want a managed service rather than managing your own servers?
• Are you working with extremely large data sets or highly complex, long-running queries? If yes, consider an MPP option.
• For a large data set, is the data source structured or unstructured? Unstructured data may need to be processed in a big data environment
• Do you want to separate your historical data from your current, operational data? If so, select one of the options where orchestration is required. These are standalone warehouses optimized for heavy read access, and are best suited as a separate historical data store.
• Do you need to integrate data from several sources, beyond your OLTP data store? If so, consider options that easily integrate multiple data sources.
• Do you have a multitenancy requirement?
• Do you prefer a relational data store? If so, choose an option with a relational data store, but also note that you can use a tool like PolyBase to query non-relational data stores if needed. If you decide to use PolyBase, however, run performance tests against your unstructured data sets for your workload.
• Do you have real-time reporting requirements? If you require rapid query response times on high volumes of singleton inserts, choose an option that supports real-time reporting.
• Do you need to support a large number of concurrent users and connections? T
• What sort of workload do you have? In general, MPP-based warehouse solutions are best suited for analytical, batch-oriented workloads. If your workloads are transactional by nature, with many small read/write operations or multiple row-by-row operations, consider using one of the SMP options. One exception to this guideline is when using stream processing on an HDInsight cluster, such as Spark Streaming, and storing the data within a Hive table

Non-relational data and NoSQL

A non-relational database is a database that does not use the tabular schema of rows and columns found in most traditional database systems. Instead, non-relational databases use a storage model that is optimized for the specific requirements of the type of data being stored. For example, data may be stored as simple key/value pairs, as JSON documents, or as a graph consisting of edges and vertices.

What all of these data stores have in common is that they don’t use a relational model. Also, they tend to be more specific in the type of data they support and how data can be queried. For example, time series data stores are optimized for queries over time-based sequences of data, while graph data stores are optimized for exploring weighted relationships between entities. Neither format would generalize well to the task of managing transactional data.

The term NoSQL refers to data stores that do not use SQL for queries, and instead use other programming languages and constructs to query the data. In practice, “NoSQL” means “non-relational database,” even though many of these databases do support SQL-compatible queries. However, the underlying query execution strategy is usually very different from the way a traditional RDBMS would execute the same SQL query.

Big data architectures

A big data architecture is designed to handle the ingestion, processing, and analysis of data that is too large or complex for traditional database systems. The threshold at which organizations enter into the big data realm differs, depending on the capabilities of the users and their tools. For some, it can mean hundreds of gigabytes of data, while for others it means hundreds of terabytes. As tools for working with big data sets advance, so does the meaning of big data. More and more, this term relates to the value you can extract from your data sets through advanced analytics, rather than strictly the size of the data, although in these cases they tend to be quite large.

Over the years, the data landscape has changed. What you can do, or are expected to do, with data has changed. The cost of storage has fallen dramatically, while the means by which data is collected keeps growing. Some data arrives at a rapid pace, constantly demanding to be collected and observed. Other data arrives more slowly, but in very large chunks, often in the form of decades of historical data. You might be facing an advanced analytics problem, or one that requires machine learning. These are challenges that big data architectures seek to solve.

Big data solutions typically involve one or more of the following types of workload:

• Batch processing of big data sources at rest.
• Real-time processing of big data in motion.
• Interactive exploration of big data.
• Predictive analytics and machine learning.

Consider big data architectures when you need to:

• Store and process data in volumes too large for a traditional database.
• Transform unstructured data for analysis and reporting.
• Capture, process, and analyze unbounded streams of data in real time, or with low latency.

Components of a big data architecture

The following diagram shows the logical components that fit into a big data architecture. Individual solutions may not contain every item in this diagram.

Most big data architectures include some or all of the following components:

• Data sources. All big data solutions start with one or more data sources. Examples include:
  • Application data stores, such as relational databases.
  • Static files produced by applications, such as web server log files.
  • Real-time data sources, such as IoT devices.
• Data storage. Data for batch processing operations is typically stored in a distributed file store that can hold high volumes of large files in various formats. This kind of store is often called a data lake. Options for implementing this storage include Azure Data Lake Store or blob containers in Azure Storage.
• Batch processing. Because the data sets are so large, often a big data solution must process data files using long-running batch jobs to filter, aggregate, and otherwise prepare the data for analysis. Usually these jobs involve reading source files, processing them, and writing the output to new files. Options include running U-SQL jobs in Azure Data Lake Analytics, using Hive, Pig, or custom Map/Reduce jobs in an HDInsight Hadoop cluster, or using Java, Scala, or Python programs in an HDInsight Spark cluster.
• Real-time message ingestion. If the solution includes real-time sources, the architecture must include a way to capture and store real-time messages for stream processing. This might be a simple data store, where incoming messages are dropped into a folder for processing. However, many solutions need a message ingestion store to act as a buffer for messages, and to support scale-out processing, reliable delivery, and other message queuing semantics. This portion of a streaming architecture is often referred to as stream buffering. Options include Azure Event Hubs, Azure IoT Hub, and Kafka.
• Stream processing. After capturing real-time messages, the solution must process them by filtering, aggregating, and otherwise preparing the data for analysis. The processed stream data is then written to an output sink. Azure Stream Analytics provides a managed stream processing service based on perpetually running SQL queries that operate on unbounded streams. You can also use open source Apache streaming technologies like Storm and Spark Streaming in an HDInsight cluster.
• Analytical data store. Many big data solutions prepare data for analysis and then serve the processed data in a structured format that can be queried using analytical tools. The analytical data store used to serve these queries can be a Kimball-style relational data warehouse, as seen in most traditional business intelligence (BI) solutions. Alternatively, the data could be presented through a low-latency NoSQL technology such as HBase, or an interactive Hive database that provides a metadata abstraction over data files in the distributed data store. Azure Synapse Analytics provides a managed service for large-scale, cloud-based data warehousing. HDInsight supports Interactive Hive, HBase, and Spark SQL, which can also be used to serve data for analysis.
• Analysis and reporting. The goal of most big data solutions is to provide insights into the data through analysis and reporting. To empower users to analyze the data, the architecture may include a data modeling layer, such as a multidimensional OLAP cube or tabular data model in Azure Analysis Services. It might also support self-service BI, using the modeling and visualization technologies in Microsoft Power BI or Microsoft Excel. Analysis and reporting can also take the form of interactive data exploration by data scientists or data analysts. For these scenarios, many Azure services support analytical notebooks, such as Jupyter, enabling these users to leverage their existing skills with Python or R. For large-scale data exploration, you can use Microsoft R Server, either standalone or with Spark.
• Orchestration. Most big data solutions consist of repeated data processing operations, encapsulated in workflows, that transform source data, move data between multiple sources and sinks, load the processed data into an analytical data store, or push the results straight to a report or dashboard. To automate these workflows, you can use an orchestration technology such Azure Data Factory or Apache Oozie and Sqoop.

Lambda architecture

When working with very large data sets, it can take a long time to run the sort of queries that clients need. These queries can’t be performed in real time, and often require algorithms such as MapReduce that operate in parallel across the entire data set. The results are then stored separately from the raw data and used for querying.

One drawback to this approach is that it introduces latency — if processing takes a few hours, a query may return results that are several hours old. Ideally, you would like to get some results in real time (perhaps with some loss of accuracy), and combine these results with the results from the batch analytics.

The lambda architecture, first proposed by Nathan Marz, addresses this problem by creating two paths for data flow. All data coming into the system goes through these two paths:

• A batch layer (cold path) stores all of the incoming data in its raw form and performs batch processing on the data. The result of this processing is stored as a batch view.
• A speed layer (hot path) analyzes data in real time. This layer is designed for low latency, at the expense of accuracy.

The batch layer feeds into a serving layer that indexes the batch view for efficient querying. The speed layer updates the serving layer with incremental updates based on the most recent data.

Data that flows into the hot path is constrained by latency requirements imposed by the speed layer, so that it can be processed as quickly as possible. Often, this requires a tradeoff of some level of accuracy in favor of data that is ready as quickly as possible. For example, consider an IoT scenario where a large number of temperature sensors are sending telemetry data. The speed layer may be used to process a sliding time window of the incoming data.

Data flowing into the cold path, on the other hand, is not subject to the same low latency requirements. This allows for high accuracy computation across large data sets, which can be very time intensive.

Eventually, the hot and cold paths converge at the analytics client application. If the client needs to display timely, yet potentially less accurate data in real time, it will acquire its result from the hot path. Otherwise, it will select results from the cold path to display less timely but more accurate data. In other words, the hot path has data for a relatively small window of time, after which the results can be updated with more accurate data from the cold path.

The raw data stored at the batch layer is immutable. Incoming data is always appended to the existing data, and the previous data is never overwritten. Any changes to the value of a particular datum are stored as a new timestamped event record. This allows for recomputation at any point in time across the history of the data collected. The ability to recompute the batch view from the original raw data is important, because it allows for new views to be created as the system evolves.
